Main uses of pneumatic vacuum feeder
A vacuum feeder is a type of vacuum conveyor that utilizes a pneumatic vacuum pump as a vacuum source. This feeder can deliver materials from a container directly into mixers, reactors, hoppers, tablet presses , packaging machines, vibrating screens, granulators, wet granulators, dry granulators, and grinders . This machine reduces labor intensity, eliminates dust pollution, and ensures GMP-compliant production.
Working principle of pneumatic vacuum feeder
When the "On/Off" button is pressed, compressed air enters the vacuum pump, and the discharge door of the hopper is closed by the cylinder, creating a vacuum in the hopper. The vacuum feeder forms an airflow under vacuum, and under the action of this airflow, the conveyed material is transported to the vacuum hopper through the hose. After a certain period of time (the feeding time is adjustable), the compressed air is turned off, the pneumatic vacuum pump cannot generate a vacuum, and the discharge door of the hopper is opened by the cylinder, the vacuum of the vacuum feeder disappears, and the material is automatically placed into the receiving equipment (such as a tablet press, packaging machine, etc.) through the discharge door. At the same time, the compressed air stored in the air bag back-blows the filter, and the filter is automatically cleaned. After a certain period of time (the discharge time is adjustable), the compressed air is restarted, the pneumatic vacuum pump generates a vacuum, the discharge door is closed, and the vacuum feeder is fed again. This cycle repeats, and the material is continuously fed into the receiving equipment.
For vacuum feeders with material level control, the material in the hopper of the receiving device is automatically fed through the material level controller. When the hopper of the receiving device is above a certain level, the vacuum feeder stops feeding; when the material level is below a certain level, the vacuum feeder automatically starts and completes feeding the receiving device.
Pneumatic vacuum feeder technical parameters
model | Delivery capacity (kg/h) | Air consumption (L/min) | Air supply pressure (MPa) |
QVC-1 | 350 | 180 | 0.5-0.6 |
QVC-2 | 700 | 360 | 0.5-0.6 |
QVC-3 | 1500 | 720 | 0.5-0.6 |
QVC-4 | 3000 | 1440 | 0.5-0.6 |
QVC-5 | 6000 | 2880 | 0.5-0.6 |
QVC-6 | 9000 | 4320 | 0.5-0.6 |
Pneumatic Vacuum Charger QVC Series – High-Efficiency Powder Conveying Solution
The Pneumatic Vacuum Charger QVC Series is an advanced material handling system designed to transfer powders and granules safely and efficiently in pharmaceutical, food, and chemical industries. By utilizing compressed air as the driving force, the QVC series provides dust-free, contamination-free, and highly reliable conveying performance, making it an ideal choice for modern automated production lines.
This document covers key aspects of the QVC series, including daily maintenance, technical specifications, available solutions, and product highlights, offering complete insight for buyers and users worldwide.
The QVC Pneumatic Vacuum Charger is engineered to meet GMP standards and ensure operator safety, process cleanliness, and high efficiency.
Dust-Free Operation: Fully enclosed conveying, preventing contamination and reducing environmental pollution.
High Efficiency: Capable of transferring large volumes of powder or granules quickly.
Energy-Saving Design: Utilizes compressed air without mechanical vibration or heat generation.
Compact & Modular Structure: Easy to install, maintain, and clean.
Versatile Applications: Compatible with tablet presses, capsule filling machines, mixers, and packaging equipment.
The following table provides the general technical indicators for the QVC Series Pneumatic Vacuum Chargers.
| Model | Conveying Capacity (kg/h) | Air Consumption (L/min) | Air Pressure (MPa) | Hopper Volume (L) | Material Contact Parts |
|---|---|---|---|---|---|
| QVC-1 | 300 – 600 | 180 | 0.4 – 0.6 | 1.5 | Stainless Steel 316L |
| QVC-2 | 600 – 1200 | 360 | 0.4 – 0.6 | 6 | Stainless Steel 316L |
| QVC-3 | 1200 – 2000 | 720 | 0.4 – 0.6 | 12 | Stainless Steel 316L |
| QVC-4 | 2000 – 3000 | 1440 | 0.4 – 0.6 | 18 | Stainless Steel 316L |
| QVC-5 | 3000 – 4000 | 2160 | 0.4 – 0.6 | 36 | Stainless Steel 316L |
Note: Custom models and capacities are available upon request to meet specific production needs.
Regular maintenance is crucial to extend the service life of the QVC pneumatic vacuum feeder and maintain stable performance.
Cleaning After Each Use
Disassemble the hopper and thoroughly clean stainless steel parts with approved cleaning solutions.
Ensure no powder residue remains in filters or conveying pipelines.
Weekly Inspection
Check for air leaks in the compressed air line.
Inspect filter cartridges and clean with compressed air if necessary.
Verify the sealing rings are intact and free from wear.
Monthly Preventive Maintenance
Inspect the pneumatic valves for smooth operation.
Check the hopper surface for any corrosion or damage.
Replace worn sealing rings or filters promptly.
Annual Overhaul
Replace filter cartridges with new ones.
Conduct a full inspection of stainless steel components.
Test compressed air supply system to ensure proper working pressure.
| Task | Frequency | Responsible Personnel |
|---|---|---|
| Hopper cleaning | After each use | Operator |
| Air leak inspection | Weekly | Maintenance staff |
| Filter cleaning | Weekly | Maintenance staff |
| Seal replacement | Monthly | Maintenance staff |
| Filter cartridge change | Annually | Technician |
To achieve optimal performance, the QVC Series Pneumatic Vacuum Charger should be installed and operated under proper conditions.
Place equipment in a clean, dry, and ventilated area.
Ensure compressed air supply is stable and meets required pressure range.
Connect to downstream equipment (tablet press, capsule filler, mixer, or packaging line) using sanitary stainless steel piping.
Follow local GMP and safety regulations during installation.
Connect compressed air line and ensure correct pressure setting.
Start the pneumatic vacuum charger and verify suction function.
Place raw material container under the suction inlet.
Monitor the conveying process; ensure powder transfer is smooth and dust-free.
Shut down the system after material transfer is complete and clean components.
The QVC Pneumatic Vacuum Charger Series provides flexible solutions across industries:
Pharmaceutical Industry
Transfer active pharmaceutical ingredients (APIs), excipients, and granules.
Integrated with tablet presses, capsule fillers, and coating machines.
Ensures GMP-compliant, dust-free, and contamination-free operation.
Food Industry
Convey powders such as flour, milk powder, starch, and food additives.
Maintains product hygiene and prevents cross-contamination.
Chemical Industry
Efficiently handles powders like resins, pigments, and fine chemicals.
Reduces exposure risks and improves workplace safety.
Nutraceuticals & Supplements
Ensures precise and clean transfer of health supplement powders.
Increases production efficiency in capsule and tablet manufacturing.
The QVC Series is designed with compressed air-driven technology that eliminates the need for complex electrical systems or motors.
Low Power Consumption: Relies on existing air supply systems.
No Heat Generation: Suitable for temperature-sensitive materials.
Minimal Maintenance Costs: Fewer moving parts reduce repair needs.
Extended Service Life: Stainless steel components ensure durability.
We provide comprehensive after-sales service to ensure the reliable operation of the QVC pneumatic vacuum charger.
12-Month Warranty covering manufacturing defects.
Spare Parts Supply: Filters, seals, and accessories available on request.
Technical Support: Online and onsite training for operators.
Global Service Network: Support for installation, troubleshooting, and maintenance.
The Pneumatic Vacuum Charger QVC Series is a reliable, efficient, and GMP-compliant powder conveying solution for industries requiring dust-free and contamination-free material handling. With robust construction, easy maintenance, and energy-saving design, it is the ideal choice for pharmaceutical, food, chemical, and nutraceutical manufacturing facilities.
By choosing the QVC series, businesses can enhance productivity, improve workplace safety, and reduce operational costs.
