Main Applications
This machine is suitable for pharmaceutical, chemical, metallurgy, food, construction and other industries. It can process hard and difficult-to-crush materials, including plastics and copper wires. It can also be used as a supporting equipment for the front-end process of micro-crushing.
Features
The machine adopts a vertical crushing mechanism , which is not limited by the viscosity, hardness, softness, etc. of the material and can achieve a good crushing effect on any material.
How it works
The material is fed into the crushing chamber from the feed hopper, and is impacted by the blade and the knife seat. The rotating knife and the fixed knife shear and crush the material at the same time. Due to the action of the rotating centrifugal force, the material automatically flows to the outlet.
Technical Parameters
model | CSJ-P |
Production capacity (kg/h) | 100-600 |
Feed size (mm) | <100 |
Discharge size (mm) | 0.5-20 |
Power (kw) | 5.5 |
Spindle speed (rpm) | 960 |
Dimensions (mm) | 780*550*1500 |
Weight (kg) | 400 |
CSJ Powerful Coarse Crusher – High-Efficiency Industrial Crushing Solution
The CSJ Powerful Coarse Crusher is a high-performance industrial crushing machine designed for rapid and efficient coarse crushing of raw materials. It is engineered for durability, reliability, and energy efficiency, making it suitable for a wide range of industries, including pharmaceutical, chemical, food, mineral, and feed production.
With its robust construction and advanced crushing mechanism, the CSJ crusher ensures consistent particle size, reduced processing time, and enhanced production efficiency. Its user-friendly design and low maintenance requirements make it an ideal solution for high-demand operations.
High Crushing Capacity
Capable of handling large volumes of raw materials quickly.
Suitable for hard and bulky materials such as minerals, herbs, and industrial solids.
Durable Construction
Built with high-strength alloy steel and reinforced components for long service life.
Resistant to wear and tear even in heavy-duty applications.
Efficient Energy Consumption
Optimized motor and crushing design minimize power usage.
High-efficiency crushing reduces processing cycles and energy costs.
Adjustable Particle Size
Allows precise control over output size.
Ensures material consistency for subsequent processing.
Easy Maintenance and Cleaning
Quick-release panels for access to crushing chamber.
Minimal downtime required for cleaning or component replacement.
Safety Features
Emergency stop and protective guards.
Overload protection to prevent motor damage.
| Model | Motor Power (kW) | Capacity (kg/h) | Feeding Size (mm) | Output Size (mm) | Material |
|---|---|---|---|---|---|
| CSJ-200 | 7.5 | 500–1,000 | ≤50 | 5–15 | Stainless Steel |
| CSJ-300 | 11 | 1,000–2,000 | ≤60 | 5–20 | Stainless Steel |
| CSJ-400 | 15 | 2,000–3,500 | ≤80 | 5–25 | Stainless Steel |
| CSJ-500 | 22 | 3,500–5,000 | ≤100 | 10–30 | Stainless Steel |
Note: Custom specifications are available based on raw material characteristics and production requirements.
The CSJ Powerful Coarse Crusher is widely used in:
Pharmaceutical Industry – crushing herbs, raw powders, and active ingredients for tablet production.
Chemical Industry – coarse crushing of raw chemical materials.
Food Industry – processing grains, nuts, and other hard food materials.
Mineral Processing – coarse crushing of ores and minerals.
Feed Production – preparing raw materials for pelletizing and granulation.
Each CSJ crusher undergoes rigorous performance testing before shipment:
Crushing Efficiency Test – ensures consistent particle size and output rate.
Durability Test – confirms wear resistance and structural integrity.
Energy Consumption Test – measures operational efficiency and power usage.
Safety Compliance Test – verifies protective guards, emergency stops, and overload protections.
Proper maintenance ensures long service life and reliable performance:
Inspect crushing chamber for material buildup.
Check motor and electrical connections.
Ensure all safety features are functional.
Clean filters, screens, and discharge chutes.
Lubricate moving parts according to manufacturer guidelines.
Inspect wear parts for early signs of damage.
Check alignment and tension of belts and chains.
Tighten bolts and structural components.
Replace worn bearings or blades as needed.
Full inspection of motors, electrical systems, and structural frame.
Upgrade key components for enhanced performance.
| Issue | Possible Cause | Recommended Solution |
|---|---|---|
| Reduced Crushing Efficiency | Worn blades or clogged chamber | Replace blades; clean crushing chamber |
| Motor Overheating | Overload or insufficient ventilation | Reduce load; inspect motor ventilation |
| Excessive Noise or Vibration | Loose bolts or misaligned parts | Tighten bolts; realign components |
| Material Sticking in Chamber | High moisture content | Pre-dry materials; clean chamber regularly |
The CSJ crusher is made of durable, high-quality components:
| Component | Material | Function |
|---|---|---|
| Crushing Chamber | Alloy Steel | Holds raw material for crushing |
| Rotor Blades | Hardened Steel | Performs coarse crushing |
| Motor & Drive System | Industrial-grade | Powers the crushing mechanism |
| Protective Guard | Steel / Mesh | Ensures operator safety |
| Discharge Chute | Stainless Steel | Guides crushed material to collection container |
| Control Panel | ABS / Metal | Adjusts motor speed and monitors operation |
High Efficiency – Rapid coarse crushing, consistent output.
Durable & Reliable – Resistant to wear and tear under heavy-duty operations.
Energy-Saving – Optimized motor and rotor design.
User-Friendly – Easy to operate, clean, and maintain.
Versatile Applications – Suitable for multiple industries and materials.
The CSJ Powerful Coarse Crusher is an essential tool for industrial coarse material processing, delivering high efficiency, durability, and energy savings. Its robust construction, adjustable output, and safety features make it ideal for pharmaceutical, chemical, food, mineral, and feed industries. With thorough performance testing, easy maintenance, and modular parts, it ensures consistent production quality and long-term operational reliability.
